Snsek-SVA8000 Veterinary Ventilator With Turbine

Snsek-SVA8000 Veterinary Ventilator With Turbine

Product Item : Snsek-SVA8000 Veterinary Ventilator With Turbine
Category： Ventilator
INQUIRY EMAIL

Brand: Penncentury SNSEK

Model:Snsek-SVA8000

Parameter	Setting Range
Tidal Volume (TV)	20 - 1500 ml
Breathing Rate (Freq)	1 - 150 bpm
Spontaneous Breathing Rate (Freq_Spont)	0 - 150 bpm
Ratio of Inhalation and Exhalation (I:E)	9:1 - 1:9 adjustable
Hold Time	0 - 50%
Flow Trigger Sensitivity (F_Tring)	0.5 - 20 L/min, OFF
Pressure Trigger Sensitivity (P_Tring)	-1 - 20 cmH2O, OFF
End-expiratory Pressure	3 - 20 cmH2O, OFF
SIMV Frequency (Freq_SIMV)	2 - 60 bpm
Inspiratory Time (T_Ins)	0.1 - 12 s
Pressure Support (PS)	0 - 60 cmH2O
Inspiratory Pressure (T_Ins)	0 - 60 cmH2O
Tidal Volume of Expiratory	0 - 2500 ml
Tidal Volume of Inspiratory	0 - 2500 ml
Minute Ventilation (MV)	Display range: 0 - 99 L/min Use range: 0 - 25 L/min
Spontaneous Minute Ventilation (MV_Spont)	Display range: 0 - 99 L/min Use range: 0 - 25 L/min
Peak Pressure (Ppeak)	0 - 80 cmH2O
Platform Pressure (Pplat)	0 - 80 cmH2O
Mean Pressure (Pmean)	0 - 80 cmH2O
Inhaled Oxygen Concentration (FiO2)	15 - 100%
End-expiratory Pressure(PEEP)	0 - 20 cmH2O
Driving Gas Pressure (Press_Drive)	0 - 900 kpa
Paw Waveform	Pressure monitoring range: 0 - 10 s
Flow-T Waveform	Y-axis: -1800 - 180 L/min X-axis: 0 - 10 s
V-T Waveform	Y-axis: 0 - 2000 L/min X-axis: 0 - 10 s

Main Features

Turbine-driven Design
No need for an external gas source, saving space and gas source costs.
Intelligent Spontaneous Mode
Avoids breathing resistance.
Lightweight and Portable
Reduces costs for animal hospitals.
Automatic Parameter Calculation
Only need to set the weight, and other parameters are calculated automatically.
Simple Operation
Equipped with a high - definition TFT touch screen. Parameters can be set via touch buttons, making the operation very easy.
Functional Features
Pressure Regulation
Has an electric PEEP function to regulate end - expiratory pressure.
Multiple Breathing Modes
Breathing modes include VCV, PCV, SPONT, etc., meeting different clinical needs.
Features a spontaneous mode, which can provide automatic ventilation when the animal has no spontaneous breathing.
Alarm and Monitoring Functions
Apnea alarm with adjustable apnea time.
Proximal respiratory flow monitoring for greater accuracy.
Suitability for Different Animal Types
Comes with bellows for large animals and small animals, specially designed for animal use.
Gas Source Characteristics
The gas source hose uses a high - grade gas source and never leaks.
Compatibility
Can be matched with veterinary anesthesia machines of different brands.
