Snsek-XG11 Vet Veterinary X-Ray System
- Product Item : Snsek-XG11 Vet
- Category： X-Ray Equipment
- Output Power:4.5Kw 100mA
- Tube:Chinese Tube
- China portable flat panel detector
- Large Size:17*17inches
Advanced Technology
-Mature flat-panel detector ensures excellent imagequality and reliable clinical diagnosis.Fast imaging time, high efficiency, directly imaging incomputer without film processing-Optimized Human-friendly Design
-Multiple self-protection and fault alarming function.
safe and reliable.
-Automatically save parameters when suddenly power offno loss of data.
-Four way floating table, electromagnetic brakeensures accurate positioning.
-Simple Operation Sharp Image
-Special veterinany radiography modeseasy to operate and safe use
-DICOM 3.0 interface supports concise imageprocessing and work list output.
-A-Si Flat Panel Detector
-Pixel pitch:154um
-Effective area:17*17inch
-Spatial resolution:3.6Lp/mm
-AD:14bit
-Model: Amorphous Silicon
-Pixel matrix:3072 3072
Configuration:
-Clinical application Radiography for limb abdomen chest etc-4.5KWOutput power
-Inverter frequency40kHz
-Tube Voltage 40kV-120kVHF High Voltage Generator and Tube Tube Current 20mA-100mA
-Radiography(mAs)1.0mAs-180mAs
Power supply220V
Exposure method Line control and remote control
