Snsek-SP-LFP612 Thermal pain tester for rats and mice
- Product Item : Snsek-SP-LFP612 Thermal pain tester for rats and m
- Category： Pain& Addiction&Inflammation
Brand: Penncentury SNSEK
Model: Snsek-SP-LFP612
The thermal pain meter for the plantar of mice and rats (thermal radiation stimulation experiment) is an instrument used in pain physiology, pharmacology and other pain research. This instrument can automatically measure the pain duration of the plantar light and heat stimulation of mice and rats in a free state. It is easy to operate and can automatically obtain the measurement results. It is an ideal experimental instrument for studying analgesic drugs in pharmacological experiments.
Parameter
Description
Number of animals in the test box
6 rats or 12 mice
Light source
Gold-plated reflective halogen light source, 800nm light wave
Pain threshold recording range
0~30.00 seconds
Timing accuracy
0.1 seconds
Light intensity control range
1%-100%
Light upper limit
1~30 seconds
Optical glass length
1000mm
Data display
5-inch touch LCD screen real-time display
Data storage capacity
2000 experimental records, can be queried at any time, automatic grouping function
With USB interface
Experimental data can be exported to USB flash drive, excel format
Optical glass thickness
6mm tempered treatment, easy to disassemble and clean
Observation box appearance and dimensions
1040X160X300mm
Power supply
110~220V 50Hz Total power: 50W
