Snsek-Medlab-SM Non-invasive Blood Pressure Measurement System

Parameters

Description

Number of measurement channels:

1~3 channels optional

Dimensions of single channel constant temperature chamber

420X290X220mm (Length x Width x Height)

Dimensions of dual-channel constant temperature chamber

530X320X280mm (Length x Width x Height)

Dimensions of three-channel constant temperature chamber

610X410X360mm (Length x Width x Height)

Constant temperature chamber temperature setting range

Room temperature ~ 45 degrees, accuracy 0.1

Pressure relief setting range

20~350mmHg

High voltage holding time

1~20 S

Automatic measurement times

1~20 P

Automatic measurement interval

1~20 S

Trigger form

Touch or TTL selectable (default touch)

Touch screen size

2.8-inch color touch screen

Tail pressure sleeve inner diameter

Rat: 11mm, Mouse: 7mm

Pulse detection method

Pressure pulse

Measuring indicators

Heart rate, systolic blood pressure, diastolic blood pressure, mean  blood pressure, pulse pressure difference, automatic statistics of mean value and standard deviation

Collection method

Can perform single acquisition, multiple acquisition

With air leakage detection function

Yes, automatic leak detection

Data recovery from acquisition software

Software with data recovery function

Data export

Data export to EXCEL, waveform export to JPG
